معرفی
سوییچ های نسل جدید C9500 مجهز به آخرین نسل ASIC شرکت سیسکو بنام UADP با قابلیت های Programmable Pipeline، microengine,
Template-basedو پشتیبانی از تمامی قابلیت های L2 ،L3 ،ACL و QOS پیشرفته می باشد.
سوییچ C9500-48YC4-A یک سوییچ پیشرفته با امکان 48 پورت 25G و با ظرفیت 3.2TBPS می باشد که در جدول زیر جزییات فنی آن آمده است:
| C9500-48Y4C-A Specification | ||
| Performance specifications | ||
| Up to 3.2 Tbps | Switching capacity | |
| Up to 1 Bpps | Forwarding rate | |
| Up to 82,000 | Total number of MAC addresses | |
| Up to 212,000 indirect + directUp to 90,000 host/ARP | Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes) | |
| Up to 212,000 indirect + directUp to 90,000 host | Total number of IPv6 routes | |
| Up to 16000 | QoS ACL scale | |
| Up to 27000 | Security ACL scale | |
| Up to 98,000 | FNF entries | |
| 16GB | DRAM | |
| 16GB | Flash | |
| 4000 | VLAN IDs | |
| 4000 | Total Switched Virtual Interfaces (SVIs) | |
| 9216 bytes | Jumbo frame | |
| Power supply specifications | ||
| C9K-PWR-650WAC-R or C9K-PWR-930WDC-R | Power Supply Selection | |
| Dimensions, physical specifications, and MTBF | ||
| 1.73x17.5 x 18.0 in | Dimensions (H x W x D) | |
| 1 RU | Rack units (RU) | |
| 90to 264 VAC | Input voltage | |
| 32°to 104°F (0° to 40°C) | Operating temperature | |
| 4°to 149°F (-20° to 65°C)- | Storage temperature | |
| Ambient (noncondensing) operating: 5% to 90%Ambient (noncondensing) nonoperating and storage: 5% to 95% | Relative humidity operating and nonoperating noncondensing | |
| Operation up to 13,000 feet at 40°C | Altitude | |
| 316,960 | MTBF (hours) | |
